2000W Pure Sine Wave Inverter Off-grid Inverter 24V 220v/230v/240v
| Model | LA-2KS-1-1 | LA-2KS-2-1 | LA-2KS-1-2 | LA-2KS-2-2 | |||||
| Continuous Power | 2000W | ||||||||
| Peak Power | 4000W | ||||||||
| DC Voltage | DC12V | DC24V | DC12V | DC24V | |||||
| AC Voltage | 100 /110 / 120VAC ± 5% （can be set by user) | 220 / 230 /240VAC ± 5% (can be set by user) | |||||||
| No Load Current Draws | 1A | 0.5A | 1A | 0.5A | |||||
| Max AC Input Current | 16.7A | 8.7A | |||||||
| DC Voltage Range | 10-15.5V | 20-31V | 10-15.5V | 20-31V | |||||
| Low Voltage Alarm | Lo0:10.5V | 11V±0.3V | Lo0:21V | 22V±0.3V | Lo0:10.5V | 11V±0.3V | Lo0:21V | 22V±0.3V | |
| Lo1:10.8V | 11.3V±0.3V | Lo1:21.6V | 22.6V±0.3V | Lo1:10.8V | 11.3V±0.3V | Lo1:21.6V | 22.6V±0.3V | ||
| Lo2:11.3V | 11.8V±0.3V | Lo2:22.6V | 23.6V±0.3V | Lo2:11.3V | 11.8V±0.3V | Lo2:22.6V | 23.6V±0.3V | ||
| Low Voltage Shut Down | Lo0:10.5V | 10.5V±0.3V | Lo0:21V | 21V±0.3V | Lo0:10.5V | 10.5V±0.3V | Lo0:21V | 21V±0.3V | |
| Lo1:10.8V | 10.8V±0.3V | Lo1:21.6V | 21.6V±0.3V | Lo1:10.8V | 10.8V±0.3V | Lo1:21.6V | 21.6V±0.3V | ||
| Lo2:11.3V | 11.3V±0.3V | Lo2:22.6V | 22.6V±0.3V | Lo2:11.3V | 11.3V±0.3V | Lo2:22.6V | 22.6V±0.3V | ||
| Low Voltage Alarm Recovery | Lo0:10.5V | 11.3V±0.3V | Lo0:21V | 22.6V±0.3V | Lo0:10.5V | 11.3V±0.3V | Lo0:21V | 22.6V±0.3V | |
| Lo1:10.8V | 11.6V±0.3V | Lo1:21.6V | 23.2V±0.3V | Lo1:10.8V | 11.6V±0.3V | Lo1:21.6V | 23.2V±0.3V | ||
| Lo2:11.3V | 12.1V±0.3V | Lo2:22.6V | 24.2V±0.3V | Lo2:11.3V | 12.1V±0.3V | Lo2:22.6V | 24.2V±0.3V | ||
| Low Voltage Protection Recovery | Lo0:10.5V | 12V±0.3V | Lo0:21V | 24V±0.3V | Lo0:10.5V | 12V±0.3V | Lo0:21V | 24V±0.3V | |
| Lo1:10.8V | 12.3V±0.3V | Lo1:21.6V | 24.6V±0.3V | Lo1:10.8V | 12.3V±0.3V | Lo1:21.6V | 24.6V±0.3V | ||
| Lo2:11.3V | 12.8V±0.3V | Lo2:22.6V | 25.6V±0.3V | Lo2:11.3V | 12.8V±0.3V | Lo2:22.6V | 25.6V±0.3V | ||
| Over Voltage Shut Down | 15.7V±0.3V | 31.5V±0.3V | 15.7V±0.3V | 31.5V±0.3V | |||||
| Over Voltage Recovery | 15.3V±0.3V | 30.6V±0.3V | 15.3V±0.3V | 30.6V±0.3V | |||||
| Frequency | 50HZ ± 0.5HZ / 60HZ ± 0.5HZ (can be set by user) | ||||||||
| Output Waveform | Pure Sine Wave | ||||||||
| AC Regulation | THD<3% (Linear load) | ||||||||
| Output Efficiency | 12V:up to 90%; 24V:up to 92% | ||||||||
| Remote Control (Optional) | Cable length: 15m is available. | ||||||||
| Power-Saving mode | The power saving mode will be activated when the output power is less than 5W. When output power is more than 10W, the inverter will automatically return to normal status. | ||||||||
| Ignition Function | Connect vehicles battery (or connect positive pole of vehicles' STARTER). The inverters start simultaneously When the vehicles start; The inverters will shut down meantime when the vehicles shut down. | ||||||||
| Protection Function | Low voltage alarm | code: F05 | Buzzer sounds and fault light turns red | ||||||
| Low voltage shutdown | code: F01 | Recover by hand after the inverter shutdown. (the inverter will auto recover when the battery voltage go back to a normal level within 20s.) | |||||||
| Over input voltage protection | code: F02 | Recover by hand after the inverter shutdown. (the inverter will auto recover when the battery voltage go back to a normal level within 20s.) | |||||||
| over load alarm | code: F06 | Buzzer sounds and fault light turns red when output power is overloaded around 110%. But the BUZZ and F06 code will not occured when the output power drop to a normal level within 20s. | |||||||
| Over load protection | code: F03 | The inverter shutdown when output power is overloaded around 120%, it need to be recovered by hand. | |||||||
| Over temperature alarm | code: F07 | Buzzer sounds and fault light turns red when the inverter's internal temperature is higher than the limit value (90±5℃). | |||||||
| Over temperature protection | code: F04 | The inverter will automatically return to normal status when the internal temperature drops to 80±5℃. | |||||||
| code: F08 | The display will show the code F08 when the thermostat in the inverters is broken | ||||||||
| Short circuit protection | code: F03 | Recover by hand | |||||||
| Reverse polarity protection | Built-in fuse | ||||||||
| Fuse | Internal | USB port | 5V, 2.1A | ||||||
| Working Temperature | -10°C--+50°C | Product Size | 351x197x82mm | ||||||
| Storage Temperature | -30°C--+70°C | Packing Size | 41x26x14cm | ||||||
| Warranty | 18 months | N.W. / G.W. (KG) | 4.5KG/5.2KG | ||||||
| Start | Bipolar soft-start | Quantity / Carton | 4pcs | ||||||
| Cooling Way | Intelligent cooling fan | Carton Size | 52x42x30cm | ||||||
| Certification | CE, E-mark, FCC | Carton Weight | 22.0KG | ||||||
Product Introduction
2000w pure sine wave inverter
1.2000W continuous pure sine wave power and 4000W surge power.Ultra- clean pure sine wave power. With less than 3% total harmonic distortion.
2.The 2000w power inverter is lighter and more compact than others with similar power ratings because they use high-frequency switching technology in the power conversion process.
3.Digital display shows the DC voltage, AC voltage, output power and some protection codes when inverter is in protection mode.
4.Power saving mode can be selectable.
Advantages
【Powerful 2000W Pure Sine Wave Inverter】2000W pure sine wave inverter efficiently converts 24V DC power to 220-240V AC power. With a peak of surge power 4000W, it provides clean, stable, and low interference power output, ensuring that all appliances work stably in the long run.
【Reliable Performance in Extreme Environments】Equipped with dual cooling fans, the inverter sustains function from freezing temperatures down to -20°C up to 40°C heat, making it suitable for a wide range of applications, including camping, off-grid solar systems and RV trips.
【100% Safety Protections】The 2000w inverter comes with all-around protections, including low voltage protection, over-voltage protection, inverter overheat prevention, and output overload protection, output short circuit protection,safe and sound.
【Easy to Install & Monitor】With 2 AC outlets, the 2000w pure sine wave inverter provides a steady and continuous power supply for AC appliances.And its monitoring screen provides instant access to the real-time status of the battery, inverter, and loads, making it easy to monitor.
【Excellent Customer Service】We provide 24-hour professional technical support and customer online service. Please feel free to contact us, we will do our best to meet your needs.
Product Details
Protecion Feature
★Over voltage and under voltage protection
★Over temperature and over load protection
★Short circuit and reverse polarity protection
FAQs
there are two main differences between a pure and modified sine-wave inverter: efficiency and cost. Pure sine wave inverters are good at two things: efficiently powering devices that use AC, and powering devices like radios that can suffer from interference. But, they can be expensive. On the other hand, a modified sine wave inverter may produce some interference, resulting in a less-than-pure current, but they are less expensive than their pure-sine counterparts.
If you are in need of an inverter that is going to power sensitive electronics such as: medical devices, computers, anything with a dimmer/variable speed, heater/heating coil, or just needs clean power; buy the pure sine inverter…
On the other hand, if you need temporary power while tail-gating, camping, road-trips or to charge your laptop/two-way radios, power fans, run a blender, power a microwave, etc., the modified sine wave inverter is smart and affordable choice
If you are not sure which one is suitable for your appliances, please contact with us.
For Inductive Load : If connecting with inductive loads (e.g. Compressor, Pump, old CRT TV, Refrigerator, Ice conditioner, Air conditioner, Relays,Fluorescent lamp, Vacuum cleaner), please choose inverter whose rate power is 3-7 times higher than the load’s rate power. For example, for a 150w refrigerator, please choose a 1000w inverter or higher; for a 800w air conditioner, please choose 2500w inverter or higher.
For Resistive Load : If connecting with resistive loads (e.g. Computer, LED TV, Fan, Scanner, Fax machine, Duplicator, Sound system, Juice extractor, Heater, Electric cooker, Coffee maker, microwave, crock pot), please choose inverter whose continuous power is a little higher than the load’s rate power. For example, for loads near 700w, it’s better to choose inverter with continuous power more than 800w.
