48V 15kwh 300AH ESS Energy Storage System Lifepo4 Battery Pack Home Solar Power Storage System

48V 15kwh 300AH ESS Energy Storage System Lifepo4 Battery Pack Home Solar Power Storage System

Short Description:

1.Long cycle life,with around 2000 times on 80% DOD

2.Smart BMS with over charging/discharging protect

3.Support multiple communication protools with RS485

4.15kw for power conversion system

5.With 2 Output specifications of 220V and 110V


Product Detail

Company Profile

Product Tags

Model No. LA-HEH48-15.0H-S1.0
Battery 15kWh
Battery Capacity 300ah
Weight 186kg
Dimension(L*D*H)mm 710*450*800
Battery Type LiFePo4
Rated Voltage  51.2V
Working Voltage Range 44.8~57.6
Maximun Charing Current 100ah
Maximun Discharing Current 100ah
DOD 80%
Communication RS485/CAN/WIFI
Charge temperature 0°C~45°C
Discharge temperature -20°C~60°C
Storage temperature -20°C~45°C
Ingress Prtection Rating IP20
Certification UN38.3,MSDS,EN55032,EN55024,EN61000-3-2,EN61000-3-3

1.Safe & reliable performance with Lithium Iron Phosphate (LFP)cell
2.Flexible inverstment with 2.5kwh modular design , scalable from 5kwh to 20kwh
3.80% depth of discharge (DoD)
4.More usable energy with pack level energy optimization

ESS(Energy Storage System) Introduction:

ess home battery

Rechargeable lithium batteries use safe lithium cell LIFEPO4. Lithium-ion batteries are rechargeable lithium-ion batteries that can be used in tandem for more energy storage. Energy input are from wind energy or solar energy etc green energy, the electrical energy storage devices, can use different times to output electricity. For example, wind energy and solar energy are unstable and not easy to supply current all the time. Combined with wall-mounted battery packs, energy storage system problems will be solved.This battery is designed to achieve market leading energy density.

ess batteries

  • Previous:
  • Next:

  • Hangzhou LIAO Technology Co.,Ltd isprofessional and leading manufacturer specialized in LiFePO4 batteries and Exporting of Green Clean Energy and relevant products.
    The lithium batteries produced by the company has good safety performance, long cycle life and high efficiency. Products range from LiFePo4 batteries, , BMS board, Inverters, as well as other relevant electrical products which can be widely used in ESS/UPS/Telecom Base Station/Residential and commercial energy storage system/ Solar Street Light/ RV/ Campers/ Caravans/ Marine /Forklifts/ E-Scooter/ Rickshaws/ Golf Cart/ AGV/ UTV/ ATV/ Medical machines/ Electric wheelchairs/Lawn mowers, etc.
    The battery products have been exported to USA, Canada, UK, France, Germany, Norway, Italy, Sweden, Switzerland, Australia, New Zealand, Jamaica, Barbados, Panama, Costa Rica, Russia, South Africa, Kenya, Indonesia, the Philippines and other countries and regions.
    With over 13 years’ experience and rapid growth, Hangzhou LIAO Technology Co.,Ltd is committed to providing our esteemed customers with reliable quality battery systems and integration solutions and will continue to innovate and improve its renewable energy products to help the world create a more eco-friendly, cleaner and brighter future.
